Name/Model

PCT-4500×12200

Plate ultrasonic defect detector

40 channels

Type of detector

Crystal Straight detector

Plate length(mm)

8000～12200

Plate width(mm)

1200～4500

Detector

using double crystal TR transducer to ensure the detecting of upper and lower dead zone is less than 2(mm)

Working speed(m/min)

3～18

Productivity

9～15

Applicable frequency for detector(MHz)

1～10

Detecting range(mm)

10～500

Horizontal linearity

≤1%

Vertical linearity

≤5%

Power of motor(kw)

3

Overall dimensions(L×W×H)(mm)

31500×7500×1700

Weight(kg)

1800
