Name/Model

ZFCT-50/1422×12200

Pipe diameter(mm)

Φ508-Φ1422

Pipe length(mm)

8000～12200

Wall thickness(mm)

8～50

Material

X70≤40、X80≤28、Q345≤50

Detecting defects

Blow holes,impurity,and delamination

Number of channels

20

Tracking range(pic)

±100

Tracking precision(mm)

±1.0

Dead zone at end of pipe(mm)

≤100

Speed of UT(m/min)

3～12

Returning speed(m/min)

30

Motor power(kw)

5.5

Power of servo motor(kw)

0.75

Power of rotating and lifting motor(kw)

2.2
